Excellent quality butyl extruder machine Eworld
Product Description
1).The machine is the specialized equipment to apply the hot melt butyl sealant to both sides of the aluminum spacing frame uniformly.
2).The operator just hold the aluminum spacing frame and all the other operations (rolling. transfer. etc.)can be completed automatically as programmed with convenient operation, stable and reliable operation, good effects of sealant extrusion and high production efficiency, it is necessarily double-glazing insulating glass manufacturing.
Butyl extruder Machine
The Main Features
1).The machine is the specialized equipment to apply the hot melt butyl sealant to both sides of the aluminum spacing frame uniformly.
2).The operator just hold the aluminum spacing frame and all the other operations (rolling. transfer. etc.)can be completed automatically as programmed with convenient operation, stable and reliable operation, good effects of sealant extrusion and high production efficiency, it is necessarily double-glazing insulating glass manufacturing.
3).Butyl glue is the double glass/insulating glass first layer sealant glue(inner sealing). If you make aluminum spacer type insulating glass, you need coat two layer sealant glue, inside it is the Butyl sealant glue.Butyl extruder machine coat the glue on the aluminum spacer frame, the aluminum frame spacer with coated Butyl glue will make the double glass stick together tightly.
Related Parameters
|
Power Supply |
220V/50Hz |
Total Power |
3.2Kw |
|
Air Pressure |
0.4-0.7mpa |
Squeeze pressure |
12-18 Mpa |
|
Brand |
Eworld |
Overall dimensions |
3200(L)x700(W)x1050(H)mm |
|
Certification |
CE |
Advantage |
Ease control |
Feature
1.Butyl extruder can process frames from 6-20mm width.
2.The feeding nozzle can be positioned to deliver uniform sealing.
3.Pneumatic operation of butyl process is controlled by a PLC that electrically regulates the temperature of the butyl heaters.
4.A timer enables the pre-heating of butyl ahead of the start of operation.
5.The height adjustment is available according to the frame size.
6.The nozzle width shall be controlled by pneumatic and hydraulic parallel method.
7.Conveyor speed can be adjusted with 5 conveyor speed.
8.Possible to control the length of butyl application and monitoring current production quantity on the touch screen.
product photo
Mechanic Details
Company Profile
*20years factory production experience
*3 years machine warranty
*156 exported country experience
*20000 square meters
Glass machine&upvc windows machine factory
*About Shandong Eworld Machine Co., Ltd.
Shandong Eworld Machine Co., Ltd is one of the famous and big manufacturers of glass equipment, windows equipment, CNC equipment. Since its inception in 2002, and after many years of development and growth, the company is now playing a leading role in glass machinery and windows door machine in China.
Eworld group has 2 factories, which are located in Jinan City. Advanced products, exquisite techniques, sold working, and cordial services
