LBZ1800 Insulating Glass Machine: Efficient and Precise Glass Insulation Solution
Insulating glass production line is the essential machine of insulating glass produciton line, it can make stepped glass, shaped glass, double layers and three layers.
This Insulating Glass Machine is special equipment for aluminum groove type insulating glass, it can make two-layer and three-layer insulating glasses with equal and unequal glass sheets.
Section details
● Lead-in conveyer: 2400*700*2400mm(Length*Width*Height)
● Washing and Drying section: 2000*1500*2600mm(L*W*H)
● Inspecting section: 2400*700*2400mm(L*W*H)
● Frane mounting section: 2400*700*2400mm(L*W*H)
● Plate press section: 2600*1200*2500mm(L*W*H)
● Tilting Table: 2400*1000*2400mm(L*W*H)
Features
Our products details
Specification
|
Main technical parameter |
|
Max working size |
1800*2500mm |
|
Min working size |
300*500mm |
|
Single Glass Thickness |
3-12mm |
|
Max IGU thickness |
50mm |
|
Washing speed |
0-8m/min |
|
Conveyor speed |
45m/min |
|
Cycle |
30—40 seconds(900*1200mm) |
|
Brusher |
3 paris |
|
Brusher Diameter |
Rough: 0.1mm, Fine: 0.06mm |
|
Electricity power |
3P 380V/50HZ or 3P 220V/60HZ |
|
Dimension |
15000*2500*3600mm |
|
Water |
0.5 ton per day |
|
Air Exhaust volume |
0.8m3/min |
|
Air pressure |
1.0Mpa |
|
Components |
|
Electricity |
CHINT/DELIXI |
|
Switch button |
CHINT/DELIXI |
|
Photoelectric switch |
Omron,Japan |
|
AC contactor |
CHINT |
|
Breaker |
Schnieder |
|
Inverter/Converter |
ENC |
|
Blower |
Jiangsu |
|
PU Pipe |
Japan |
|
Brusher |
Anhui |
|
Roller |
Anhui |
|
Water pump |
Shanghai |
|
Motors |
Chengbang(Taiwai) |
|
Machining processing（Frame, welding, mould, painting., etc） |
EWORLD factory |
